Label Stock Coating and Laminating Machine
    • Label Stock Coating and Laminating Machine
Product Details

Applications:

- Professionally designed for silicone release coating, chrome paper lamination, electrostatic film lamination, inkjet printinting buslogisitics truck ads materials and other label stock products.


Technical Parameters:

- Substrate width: 1,300mm or 1,600mm

- Max unwinding diameter: 1,200mm

- Max rewinding diameter: 1,200mm

- Coater available: comma and transfer coater

- Heating source: Electricity, steam, thermal oil or hot air

- Mechanical Speed: 20-200m/min


Key Features:

- Full automatic tension control in segmented tension zones, tension variation is less than ±3N in production

- Good adhesive evenness, dry adhesive thickness tolerance is less than ±1μ

- High drying efficiency and low energy consumption

- Automatic humidifier control

- Double position unwind and rewind with automatic splice and cutting off

- Integrated menu management with easy accessibility and operation

- Optional design: Energy recycling system, automatic thickness detect and control system
