PET Electric Tape Coating Machine
    • PET Electric Tape Coating Machine
Product Details


-  Designed for coating production of PET electronic tape, PET protective film for smartphone or pad screen, PET double side tape and PET silicone release film.

Technical Parameters:

- Substrate width: 1,100mm, 1,300mm or 1,600mm

- Max unwinding diameter: 1,000mm

- Max rewinding diameter: 1,000mm

- Coater available: Microgravure coater, comma coater, transfer coater or slot die coater

- Heating source: Electric, steam, thermal oil or hot air

- Mechanical Speed: 20-200m/min

Key Features:

- Stable tension control system, tension variation is less than ±3N in production

- Good adhesive evenness, dry adhesive thickness tolerance is less than ±1μ

- High drying efficiency and low energy consumption

- Double position unwind and rewind with automatic splice and cutting off

- Integrated menu management with easy accessibility and operation

- Optional design: Energy recycling system, automatic thickness detect and control system and bubble free length-select rewinder
